NOVOS 3 move
NOVOS 3 move UP CO2 white TLF
CO2 Traffic Light, Room sensor CO2 | | 0..+50 °C
| Application/type | CO2 Traffic Light, Room sensor |
|---|---|
| Purpose | Measure values |
| Sensor elements | CO2 |
| Measured values | CO2 |
| On stock | No |
| Operating range temperature (°C) | 0..+50 |
| Operating ranges temperature (°C) | 0..+50 |
| Measuring range CO2 | 0..5000 ppm |
| Accuracy CO2 | ±50 ppm +3% of measured value (typ. at 21 °C, 50% rH, 1015 hPa) |
| Power supply | Flush-mounted power supply 230 V (±10%, 50/60 Hz), max. 0.4 A |
| Power consumption | typ. 0,4 W (24 V =) |
| Display | RGB LED, with traffic light function, threshold values configurable, optionally configurable via app or uConfig |
| Enclosure | NOVOS 3, PC V0 |
| Colour | pure white, black |
| Protection (IP) | IP20, according to EN 60529 |
| Connection | tool-free mountable spring clamp, max. 1,5 mm², cable entry via rear opening |
| Mounting | flush-mounted on standard EU box (Ø=60 mm), base part can be mounted and wired separately |
| Packaging length (mm) | 115 |
| Packaging width (mm) | 105 |
| Packaging height (mm) | 30 |
| Packaging | case packaging |
| Device length (mm) | 110 |
| Device width (mm) | 100 |
| Device height (mm) | 23 |
| Gefahrgut | No |
