| Application/type |
Window contact |
| Purpose |
Room Climate Control |
| Interface |
EnOcean (868 MHz) |
| Sensor |
reed contact and magnet |
| Radio technology |
EnOcean (IEC 14543-3-10) 868 MHz, 902 MHz, transmission power <10 mW, radio telegram, EEP D5-00-01 (1BS) |
| Data transmission |
immediately on change of state, every 1000 seconds |
| Operating range temperature (°C) |
-20..+60 |
| Operating ranges temperature (°C) |
-20..+60 |
| Operating range humidity |
max. 85% rH non-condensing |
| Power supply |
solar cell, maintenance-free internal super cap, use of back-up battery possible for insufficiently lit environments, coin cell CR1225, battery type AAA |
| Enclosure |
PC V0 |
| Colour |
pure white |
| Protection (IP) |
IP20, according to EN 60529 |
| Mounting |
surface-mounted flat on base using included adhesive pad or screws |
| Delivery content |
incl. adhesive foil for mounting, incl. battery type AAA, incl. coin cell type CR1225 |
| Packaging length (mm) |
150 |
| Packaging width (mm) |
100 |
| Device width (mm) |
21 |
| Device height (mm) |
15 |
| Notes |
for 1 or 2-leaf windows, Please note our sheet 'Information EasySens® Radio' |
| Gefahrgut |
No |
